Aluminium 2024 Alloy Powder from Nanografi is an aluminium-copper-magnesium-manganese alloy (AlCuMgMn) supplied as a fine powder with a particle size of -325 mesh. It is offered in 100 g, 500 g and 1000 g packs.
The 2024 grade is known for its high strength combined with a favourable strength-to-weight ratio and excellent fatigue resistance, making it a choice for demanding structural and mechanical components. Machinability is adequate, while corrosion resistance and surface finish capabilities are limited, which should be considered when selecting the material.
Typical properties include a density of 2.78 g/cm3, a melting range of 502-638 °C, an ultimate tensile strength of 469 MPa, thermal conductivity of 121 W/m-K and a Vickers hardness of 137. Copper (3.8-4.9) and magnesium (1.2-1.8) are the main alloying elements, with aluminium as the balance.
- Production of aircraft fittings, missile parts and munitions components.
- Manufacture of gears, worm gears, shafts and couplings.
- Fabrication of fasteners such as bolts, nuts and other fastening devices.
- Parts for pistons, hydraulic valve bodies, fuse parts and rectifier parts.
- Components for clocks, computers, and veterinary and orthopedic equipment.
- General structural parts requiring a high strength-to-weight ratio.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | AlCuMgMn |
| Purity | — |
| Category | — |
| Pack sizes | 100 g, 500 g, 1000 g |
| Physical form | Powder |
| Storage | — |
- Product code: NG04EO072362
- Particle Size: - 325 mesh
- Melting Point: 502-638 °C
- Density: 2.78 g/cm3
- Poisson's Ratio: 0.33
- Specific Heat: 0.875 J/g-°C
- Tensile Strength: 469 MPa (Ultimate)
- Thermal Conductivity: 121 W/m-K
- Thermal Expansion: 23.2-24.7 µm/m-°C
- Vickers Hardness: 137
- Elemental Analysis: Si ≤0.5, Mn 0.3-0.9, Cr ≤0.1, Zn ≤0.25, Al Bal, Mg 1.2-1.8, Cu 3.8-4.9, Ti ≤0.15, Fe ≤0.5
—
—
