This is a spherical aluminium 6061 alloy powder with a particle size range of 15-53 µm. The alloy is based on aluminium with magnesium, silicon, copper and chromium as its main alloying elements, and it appears as a silvery-gray powder.
Aluminium 6061 is valued for its combination of relatively high strength, good workability and high corrosion resistance, and it also accepts applied coatings well. Typical property values include an ultimate tensile strength of 310 MPa, a Vickers hardness of 107, a thermal conductivity of 167 W/m-K and a density of 2.5-2.9 g/cm3.
These characteristics make the powder a candidate material for components used in aerospace, marine, automotive, electrical and general hardware applications.
- Production of aircraft fittings and camera lens mounts.
- Manufacture of couplings, marine fittings and marine hardware.
- Fabrication of electrical fittings and connectors.
- Making brake pistons, hydraulic pistons, valves and valve parts.
- Producing hinge pins, magneto parts, appliance fittings and decorative hardware.
- Building bike frames.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | Al/Mg/Si/Cu/Cr |
| Purity | — |
| Category | — |
| Pack sizes | 100 g, 500 g, 1000 g |
| Physical form | Silvery-Gray Powder |
| Storage | — |
- Product code: NG04EO072361
- Particle Size: 15-53 µm
- Morphology: Spherical
- Melting Point: 482-660 °C
- Boiling Point: 2519 °C
- Density: 2.5-2.9 g/cm3
- Poisson's Ratio: 0.33
- Specific Heat: 0.896 J/g-°C
- Tensile Strength: 310 MPa (Ultimate)
- Thermal Conductivity: 167 W/m-K
- Thermal Expansion: 23.6 µm/m-°C (20-100 °C)
- Vickers Hardness: 107
- Elemental Analysis (%): Si 0.4-0.8, Mn ≤0.15, Cr 0.04-0.35, Zn ≤0.25, Al Bal, Mg 0.8-1.2, Cu 0.15-0.40, Ti ≤0.15, Fe ≤0.7
—
—
