This boron carbide (B4C) sputtering target from Nanografi is a 2'' target with a thickness of 0.125'' and a purity of 99.5%, supplied with indium bonding. It serves as the source material for depositing B4C thin films in sputter coating systems.
Sputter deposition works by eroding material from the target and transferring it onto a substrate such as a silicon wafer. The method suits substrates of many shapes and sizes, gives repeatable results, and can move from small research and development runs to production batches covering medium to large substrate areas.
Because the process has many adjustable parameters, experienced users can exert considerable control over film growth and microstructure. Depending on process conditions, chemical reactions may take place at the target surface, in flight, or on the substrate itself.
- Thin film deposition of boron carbide onto substrates such as silicon wafers.
- Sputter etching where a high degree of etching anisotropy is required and selectivity is not a concern.
- Materials analysis techniques such as secondary ion mass spectrometry (SIMS), where material is sputtered at a constant rate and analysed by mass spectrometry.
- Physical vapor deposition (PVD) coating work, from research scale to medium and large substrate areas.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.5% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01BO18
- Material: Boron Carbide (B4C)
- Size: 2''
- Thickness: 0.125''
- Bonding: Indium
- Product code: NG0ST01BO18
—
—
