This thermoplastic carbon paste is a conductive ink for screen printing, formulated so a structure can be printed in one piece with a single screen. It is aimed at electronics and energy applications where good conductivity, thermal stability and reliable printability are needed.
The paste is cured at a low temperature: printed structures are processed in a convection oven at 140 °C for 30 to 60 minutes, giving a sheet resistance of 50 Ω/sqr/25 µm. Uncured viscosity is 2.5-5 Pa.s @ 50 s^-1, and the cured film reaches 5B adhesion with an instrumented hardness of about 120 MPa and a Martens hardness of about 95 MPa.
It is suited to PET and glass substrates and is specified for a stainless steel screen with 13 µm emulsion at 325 DPI. The low curing temperature makes it a practical choice for heat-sensitive polymer films.
- Printing flexible circuits on polymer substrates with stable electrical conductivity.
- Forming conductive layers in electrochemical and biological sensors.
- Printing low-temperature electrodes for organic and thin-film photovoltaic cells.
- Creating contact points in pressure-sensitive membrane keyboard layers.
- Acting as a conductive additive in supercapacitor and battery electrodes.
- Printing sensor circuits and control modules in automotive electronics.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | — |
| Category | — |
| Pack sizes | 100 g, 250 g, 1000 g |
| Physical form | — |
| Storage | — |
- Product code: NG10CAP0902
- Curing temperature: 140 °C
- Curing time: 30 to 60 minutes (convection oven)
- Sheet resistance (cured): 50 Ω/sqr/25 µm
- Viscosity (uncured): 2.5-5 Pa.s @ 50 s^-1
- Adhesion: 5B
- Instrumented hardness (HIT): ≈ 120 MPa
- Martens hardness (HM): ≈ 95 MPa
- Substrate: PET, Glass
- Screen: 13 µm emulsion, 325 DPI, SS
—
—
