This conductive graphite powder is a primary synthetic graphite designed for lithium-ion battery work, where it can act both as an anode active material and as a conductive component in electrode formulations. It is made by high-temperature graphitization, giving a stable crystalline structure that stays consistent from lot to lot.
The grade is specified at 99.9+% purity with a particle size of 1-5 µm, a specific surface area of 17 m²/g and a density of 2.26 g/cm³. Ash content is below 0.02% and moisture below 0.25%, with metallic impurities kept under tight control to limit unwanted side reactions in sensitive electrochemical systems.
Its layered carbon structure supports reversible lithium-ion intercalation while providing electronic conductivity. The narrow particle size distribution and controlled surface area make the powder easy to process into slurries and coatings, and useful for studies of electrode composition, conductivity and processing behaviour, including composite anodes investigated together with silicon.
- Anode active material and conductive additive for lithium-ion battery chemistries in energy storage systems.
- High-capacity batteries for smartphones, tablets and laptops that need long cycle life and stability.
- Power-dense battery packs for e-bikes, scooters and lightweight urban electric vehicles.
- Drone and UAV batteries that demand high energy density and steady power delivery.
- High-discharge battery systems for cordless professional power tools.
- High-purity carbon additive for conductive polymers, coatings and composite matrices.
| Brand | Nanografi |
|---|---|
| CAS number | 7782-42-5 |
| Molecular formula | — |
| Purity | 99.9+% |
| Category | — |
| Pack sizes | 25gr, 100gr, 500gr, 1000gr |
| Physical form | — |
| Storage | — |
- Product code: NG08BE0303
- Product code: NG08BE0303
- Particle size: 1-5 µm
- Ash: < 0.02%
- Moisture: <0.25%
- Specific surface area: 17 m²/g
- Density: 2.26 g/cm³
- Type: Primary synthetic graphite
Keep the powder in tightly sealed containers in a clean, dry place and follow the product Safety Data Sheet (SDS). Limit airborne dust with ventilation, containment and protective equipment during weighing and mixing. Fine carbon powders can pose a combustible dust hazard, so control ignition sources and dust build-up.
—
