These are short single walled carbon nanotubes (SWCNTs) carrying carboxyl (-COOH) groups on their surface, with a -COOH content of 2.7%. Produced by CVD, the black powder has a purity above 92 %, an outer diameter of 1-2 nm, an inner diameter of 0.8-1.6 nm and tube lengths of 1-3 µm.
The carboxyl groups make the tubes easier to disperse in water and polar solvents and give reactive sites for covalent attachment of biomolecules, metal ions and polymers. The shortened length raises surface accessibility and edge reactivity, which suits work where nanotubes must mix evenly into a matrix or interact with active species.
Key properties include a specific surface area of 370 m2/g, electrical conductivity of 98 S/cm, thermal conductivity of 45-190 W/m.K and an Ig/Id ratio of 9. The material is offered in 5, 25, 100, 500 and 1000 gram packs.
- Drug delivery carriers, biosensors and bioimaging agents that benefit from aqueous dispersibility and covalent bonding with biomolecules.
- Catalyst supports for heterogeneous catalysis, photocatalysis and template-assisted synthesis.
- Reinforcing filler in polymer composites, adhesives, films and coatings to improve mechanical, thermal and electrical performance.
- Electrode additives for lithium-ion batteries, supercapacitors and fuel cells.
- Transparent conductive films, thin-film transistors, flat panel displays and gas-discharge tubes.
| Brand | Nanografi |
|---|---|
| CAS number | CVD / 308068-56-6 |
| Molecular formula | — |
| Purity | > 92 % |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: NG01SW0203
- Content of (-COOH): 2.7%
- Color: black
- Average Diameter: 1.0 nm
- Length: 1-3 µm
- Outer Diameter (OD): 1-2 nm
- Inner Diameter (ID): 0.8-1.6 nm
- Tap Density: 0.15 g/cm3
- True Density: 2.2 g/cm3
- Specific Surface Area (SSA): 370 m2/g
- Ash: 1.5 wt%
- Thermal Conductivity: 45-190 W/m.K
- Electrical Conductivity: 98 S/cm
- Ig/Id: 9
—
—
