This copper (Cu) nanopowder from Nanografi consists of spherical particles with an average size of 500 nm and a purity of 99.9+%. The reddish brown powder has a cubic crystal structure and is supplied for work where the high electrical conductivity of copper nanoparticles is needed, chiefly in the electronics industry.
Elemental analysis gives a copper content of ≥ 99.95, with iron at ≤ 0.02, nickel at ≤ 0.01 and other elements at ≤ 0.01. The powder has a specific surface area of 4,6 m2/g, a bulk density of 0,7-1,1 g/cm3 and a true density of 8,9 g/cm3.
Typical uses include conductive coatings, inks and pastes, raw material for electronic components, catalysis for reactions such as methanol production, lubricant additives, wear resistant coatings and sintering additives.
- Formulation of conductive coatings, inks and pastes for electronics.
- Raw material for electronic parts and microelectronic devices.
- Catalysis for reactions such as methanol production.
- Additive for lubricants.
- Component of wear resistant coatings.
- Sintering additive.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.9+% |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: NG04EO1003
- Average Particle Size: 500 nm
- Shape: spherical
- Color: reddish brown
- Crystal Structure: cubic
- Specific Surface Area: 4,6 m2/g
- Bulk Density: 0,7-1,1 g/cm3
- True Density: 8,9 g/cm3
- Cu: ≥ 99.95
- Fe: ≤ 0.02
- Ni: ≤ 0.01
- Others: ≤ 0.01
Copper nanoparticles are highly reactive and flammable, so handle them carefully and avoid rapid movements and vibration. Keep the powder away from sunlight, heat, moisture, impacts and air contact. To limit particle coagulation, store it sealed under vacuum in cool, dry conditions. Refer to the MSDS before use.
—
