This indium oxide (In2O3) sputtering target from Nanografi is a 99.99% purity source material for depositing thin films by sputtering. Each piece measures 2'' in size with a thickness of 0.250''.
Sputter deposition works by eroding material from the target and transferring it onto a substrate such as a silicon wafer. The technique handles a broad range of materials and substrate shapes and sizes, gives repeatable results, and can grow from small research and development work into production batches covering medium to large substrate areas.
Depending on process parameters, chemical reactions may take place at the target surface, in flight or on the substrate. Although the large number of variables makes sputtering a complex process, it gives experienced users considerable control over film growth and microstructure.
- Deposition of indium oxide thin films onto substrates such as silicon wafers.
- Sputter etching where a high degree of etching anisotropy is required and selectivity is not a concern.
- Material analysis such as secondary ion mass spectrometry (SIMS), where sputtered atoms are identified and quantified to determine composition and detect trace impurities.
- Research into space weathering processes affecting airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.99% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01IN38
- Material: Indium Oxide (In2O3)
- Size: 2''
- Thickness: 0.250''
- Product code: NG0ST01IN38
—
—
