This Iron (Fe) micron powder from Nanografi is a metallic iron powder with 99% purity and a particle size of 100 mesh. It is identified by CAS number 7439-89-6 and is supplied as a powder for use as a filler material in plastics and polymer systems.
Iron has a density of 7.87 g/cm³, a melting point of 1536 °C and a boiling point of 3000 °C. Its crystal structure is body-centred cubic, its Brinell hardness lies in the 82 – 100 range, and its electrical resistivity is 9.71 microhm-cm. The coefficient of expansion at 20 °C is 12.6 x 10 ⁻⁶.
The powder is offered in 25gr, 100gr, 500gr and 1000gr packs, covering small laboratory trials as well as larger formulation work.
- Used as a filler material in compounded formulations.
- Added to plastics to modify the properties of the base resin.
- Incorporated into polymer matrices for composite development.
| Brand | Nanografi |
|---|---|
| CAS number | 7439-89-6 |
| Molecular formula | — |
| Purity | 99 % |
| Category | — |
| Pack sizes | 25gr, 100gr, 500gr, 1000gr |
| Physical form | Powder |
| Storage | — |
- Product code: NG01CM1403
- Particle Size: 100 mesh
- Density: 7.87 g/cm³
- Boiling Point: 3000 °C
- Melting Point: 1536 °C
- Coeff. of Expansion @ 20ºC: 12.6 x 10 ⁻⁶
- Brinell Hardness: 82 – 100
- Electric Resistivity: 9.71 microhm-cm
- Crystal Structure: Cubic, Body Centered
—
—
