This manganese (Mn) sputtering target from Nanografi has a purity of 99.95%, a 2'' size and a thickness of 0.125'', and is supplied as a single piece with indium. It serves as the source material in sputter deposition, where atoms are eroded from the target and laid down as a thin film on a substrate such as a silicon wafer.
Sputtering is an established route for coating substrates of many shapes and sizes. The process is repeatable, works for small research and development runs, and can be adapted to production batches covering medium to large substrate areas. Depending on process conditions, chemical reactions may take place at the target surface, in flight or on the substrate.
Because sputter deposition involves many adjustable parameters, it gives experienced users considerable control over film growth and microstructure.
- Deposition of manganese thin films onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Material analysis by etching, for example in secondary ion mass spectrometry (SIMS) to determine composition and detect trace impurities.
- Scaling sputter processes from research and development work to medium and large area production batches.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.95% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01MN12
- Material: Manganese (Mn)
- Size: 2''
- Thickness: 0.125''
- Bonding: Indium
—
—
