This manganese (Mn) sputtering target from Nanografi is supplied with indium bonding, has a purity of 99.95%, a size of 3'' and a thickness of 0.125''. It serves as the source material for sputter deposition of manganese thin films onto substrates such as silicon wafers.
Sputtering is an established method for coating substrates of many shapes and sizes. The process gives repeatable results and scales from small research and development work to production batches covering medium to large substrate areas. Depending on the process parameters, chemical reactions can take place at the target surface, in flight or on the substrate. The large number of adjustable parameters makes the process complex, but it also gives experienced users close control over film growth and microstructure.
- Deposition of manganese thin films onto substrates such as silicon wafers.
- Sputter etching where strong etching anisotropy is required and selectivity is not a concern.
- Material analysis by sputtering, for example in secondary ion mass spectroscopy (SIMS) to determine composition and detect trace impurities.
- Research related to space weathering, in which sputtering alters the surfaces of airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.95% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01MN13
- Material: Manganese (Mn)
- Bonding: Indium
- Size: 3''
- Thickness: 0.125''
- Product code: NG0ST01MN13
—
—
