Mesocarbon Microbeads (MCMB) Graphite Micron Powder is a highly graphitized, spherical carbon powder intended mainly as an anode active material for lithium-ion batteries. It is made by controlled thermal treatment followed by graphitization, giving uniform particles with a D50 of 9-15 μm, carbon content of ≥99.95%, ash of ≤0.05% and moisture held at ≤0.2%.
The ordered crystalline structure and isotropic, spherical particles give the powder good electrical conductivity, a tapped density of ≥1.2 g/cm³ and a specific surface area of 1.2-2.2 m²/g. In electrochemical testing it reaches an initial discharge capacity of ≥320 mAh/g with an initial coulombic efficiency of ≥93%.
During repeated charge-discharge cycling the material keeps its structure stable with little volume expansion, which supports efficient cycling and long service life. It is offered in 500 gr and 1000 gr packs.
- Anode active material for high-performance lithium-ion batteries aiming at high energy density and structural durability.
- Power batteries for electric vehicles that need fast charge-discharge rates and long cycle life.
- Large-scale energy storage systems relying on stable cycling performance.
- Battery cells for smartphones, laptops and other portable electronics.
- Functional conductive filler in conductive polymers, coatings and advanced carbon composites.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | — |
| Category | — |
| Pack sizes | 500 gr, 1000 gr |
| Physical form | — |
| Storage | — |
- Product code: NG08BE0307
- Average Particle Size (D50): 9-15 μm
- Maximum Particle Size (Dmax): ≤50 μm
- Carbon Content: ≥99.95%
- Tapped Density: ≥1.2 g/cm³
- True Density: ≥2.2 g/cm³
- Specific Surface Area: 1.2-2.2 m²/g
- Initial Discharge Capacity: ≥320 mAh/g
- Initial Coulombic Efficiency: ≥93%
- Ash Content: ≤0.05%
- Moisture Content: ≤0.2%
—
—
