This molybdenum disulfide (MoS2) sputtering target has a purity of 99.9%, a size of 4'' and a thickness of 0.250''. It serves as the source material in sputter deposition, where atoms are eroded from the target and deposited as a thin film onto a substrate such as a silicon wafer.
Sputtering can coat substrates of many shapes and sizes. It gives repeatable results and scales from small research and development work up to production batches covering medium to large substrate areas. Depending on the process parameters, chemical reactions can take place on the target surface, in flight or on the substrate. These many parameters make the process complex, but they also give experienced users close control over film growth and microstructure.
- Deposition of MoS2 thin films onto substrates such as silicon wafers.
- Sputter etching in cases where strong etching anisotropy is required and selectivity is not critical.
- Material analysis by sputtering, such as secondary ion mass spectrometry (SIMS) to determine composition and detect trace impurities.
- Research and development work that can later be scaled up to production on medium to large substrate areas.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.9% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01MO40
- Material: Molybdenum Disulfide (MoS2)
- Size: 4''
- Thickness: 0.250''
- Product code: NG0ST01MO40
—
—
