This product is a multi walled carbon nanotube (MWCNT) array grown on a quartz substrate, supplied as a 1cm x 1cm piece. The nanotube layer reaches a height of 490 µm and the MWCNT purity is 99 wt%.
The individual nanotubes have an outside diameter of 7-20 nm and an inside diameter of 3-7 nm. The array has a density below 0.30 g/cm3, a specific surface area of 28 m2/g and an electrical conductivity of 1100 S/m.
Its good electrical conduction, combined with a large surface area that helps carry heat away efficiently, makes the array a candidate material for work in microelectronics, sensing and power devices.
- Research and development of microelectronic components that need conductive carbon nanostructures.
- Fabrication and testing of sensors based on carbon nanotube arrays.
- Power-related applications that benefit from high electrical conductivity.
- Studies of heat dissipation using high-surface-area nanotube layers.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99 wt% |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: NG01SC0208
- Size: 1cm x 1cm
- Substrate: Quartz
- Outside Diameter: 7-20 nm
- Inside Diameter: 3-7 nm
- Array Height: 490 µm
- Density: <0.30 g/cm3
- Specific Surface Area: 28 m2/g
- Electrical Conductivity: 1100 S/m
A Material Safety Data Sheet (MSDS) is available for this product and should be consulted before handling.
—
