This multi-walled carbon nanotube (MWCNT) dispersion in isopropanol (IPA) delivers a high nanotube loading of 10 wt% in a quick-drying alcohol carrier. The nanotubes have a purity above 95%, an outer diameter of 30-80 nm, an inner diameter of 5-15 nm and a length below 10 µm. The material is suited to industrial formulation work where electrical and thermal conductivity must be built into a matrix.
Because isopropanol has low surface tension, the dispersion wets substrates well and dries rapidly, which suits spray coating and high-throughput production. Supplied as a stable liquid, it removes the need to handle dry nanotube powder and makes it simpler to incorporate MWCNTs into coatings, inks, composites and electrodes.
The product is available in 15 ml, 30 ml, 60 ml and 120 ml pack sizes.
- Formulating fast-drying conductive and anti-static (ESD) coatings for automotive parts, electronic housings and industrial flooring.
- Producing high-loading EMI/RFI shielding paints and sprays for sensitive electronic equipment.
- Acting as a concentrated masterbatch for alcohol-compatible resins and polymers to improve mechanical strength and electrical properties.
- Preparing battery and supercapacitor electrodes where an alcohol-based solvent suits the chosen binder.
- Making conductive inks for screen printing or spray-pyrolysis of flexible circuits and sensors.
- Adding to protective coating systems to improve barrier properties and durability against corrosion.
| Brand | Nanografi |
|---|---|
| CAS number | 308068-56-6 |
| Molecular formula | — |
| Purity | >95% |
| Category | — |
| Pack sizes | 15 ml, 30 ml, 60 ml, 120 ml |
| Physical form | — |
| Storage | — |
- Product code: NG02CN0113
- MWCNT Content: 10 wt%
- Outer Diameter: 30-80 nm
- Inner Diameter: 5-15 nm
- Length: <10 µm
- Specific Surface Area: >60 m2/g
- Tap Density: 0.18 g/cm3
- Carrier: Isopropanol (IPA)
- CAS No (Isopropanol): 67-63-0
—
—
