This niobium oxide (Nb2O5) sputtering target from Nanografi is a source material for depositing thin films by sputtering. It has a purity of 99.5%, a size of 8'' and a thickness of 0.250'', and is supplied as a single piece.
In sputter deposition, material is eroded from the target and transferred onto a substrate such as a silicon wafer. The method works with many materials and substrate geometries, gives repeatable results, and can move from small research and development work to production batches covering medium to large substrate areas.
Depending on the process settings, chemical reactions may take place at the target surface, during transit or on the substrate itself. The number of adjustable parameters makes the process complex, but it gives experienced users considerable control over film growth and microstructure.
- Deposition of niobium oxide thin films onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Material analysis by etching, such as secondary ion mass spectrometry (SIMS), to determine composition and detect very low impurity levels.
- Research into space weathering processes that alter airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.5% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST02NI40
- Material: Niobium Oxide (Nb2O5)
- Size: 8''
- Thickness: 0.250''
- Product code: NG0ST02NI40
—
—
