These meniscus guides are stainless steel accessories for the Ossila 50 mm standard slot die head. Fitted to the coating head, they pin the edges of the liquid meniscus so the deposited film keeps a controlled, clearly defined width during slot die coating.
Each pack contains 3 guides. The range is offered with predefined coating widths, lip depths of 0.5 mm, 1 mm or 1.5 mm, and guide thicknesses of 0.05 mm or 0.1 mm, so the guide can be matched to the coating job. They are suited to inks with viscosities from 0 – 1000 cPs.
Where standard sizes are not enough, custom versions can be made, including designs for coating several strips at once. The guides sit within a wider slot die coating range that also includes slot die heads and shims for defining film width.
- Pinning the coating width when depositing thin films with the Ossila 50 mm slot die head.
- Producing better defined film edges in slot die coating of solutions from 0 – 1000 cPs.
- Multi-strip slot die coating using custom meniscus guide designs.
| Brand | Ossila |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | — |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: L3005M3-15
- Compatible with: Ossila 50 mm standard slot die head
- Material: Stainless steel
- Viscosity Range: 0 – 1000 cPs
- Guide Thickness: 0.05 mm, 0.1 mm
- Lip Depth: 0.5 mm, 1 mm, 1.5 mm
- Number per Pack: 3
—
—
