These meniscus guides are stainless steel accessories for slot die coating. They fit the Ossila 50 mm standard slot die head and help fix, or pin, the width of the coated film so that the deposited layer has better defined edges.
Each pack contains 3 guides. Versions are offered with different predefined coating widths, lip depths and guide thicknesses, so the guide can be matched to the coating job. Guide thickness options are 0.05 mm and 0.1 mm, and lip depth options are 0.5 mm, 1 mm and 1.5 mm. The guides are suited to fluids in the 0 – 1000 cPs viscosity range.
Custom guides can also be specified for more particular needs, including setups for coating multiple strips. The guides sit alongside slot die heads and shims in the Ossila slot die coating range, which can be combined to tailor a coating setup.
- Pinning the coating width during slot die coating with the Ossila 50 mm standard slot die head.
- Producing thin films with better defined edges and widths.
- Multi-strip slot die coating using custom guide configurations.
| Brand | Ossila |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | — |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: L3005P3-25
- Compatible with: Ossila 50 mm standard slot die head
- Material: Stainless steel
- Viscosity Range: 0 – 1000 cPs
- Guide Thickness: 0.05 mm, 0.1 mm
- Lip Depth: 0.5 mm, 1 mm, 1.5 mm
- Number per Pack: 3
—
—
