These meniscus guides are accessories for slot die coating that fix the edges of the coating meniscus, so the deposited film has a clearly defined width. They are designed to fit the Ossila 50 mm standard slot die head and are made from stainless steel.
Each pack contains 3 guides. Versions are offered with set coating widths, guide thicknesses of 0.05 mm or 0.1 mm, and lip depths of 0.5 mm, 1 mm or 1.5 mm, letting users match the guide to their process. The guides suit inks and solutions within a viscosity range of 0 – 1000 cPs.
Custom guides can also be supplied for more specialised work, including designs that produce multiple coated strips in one pass. The guides work alongside other slot die accessories such as slot die heads and shims, which also help define the width of the coated film.
- Pinning the coating width during slot die coating with the Ossila 50 mm standard slot die head.
- Producing thin films with better defined edges and widths.
- Multi-strip slot die coating using custom guide designs.
- Coating solutions with viscosities between 0 and 1000 cPs.
| Brand | Ossila |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | — |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: L3005P3-50
- Compatible with: Ossila 50 mm standard slot die head
- Material: Stainless steel
- Viscosity Range: 0 – 1000 cPs
- Guide Thickness: 0.05 mm, 0.1 mm
- Lip Depth: 0.5 mm, 1 mm, 1.5 mm
- Number per Pack: 3
—
—
