This Nanografi selenium (Se) sputtering target is supplied as an elastomer-type target with 99.999% purity, a 2'' size and a thickness of 0.125''. It serves as the source material for sputter deposition, where material is eroded from the target and deposited as a thin film onto a substrate such as a silicon wafer.
Sputtering is an established method for coating many different substrate shapes and sizes. The process is repeatable, works for small research and development runs, and can be scaled to production batches covering medium to large substrate areas. Depending on process parameters, chemical reactions may take place on the target surface, in flight or on the substrate. The many adjustable parameters make the process complex, but they give experienced users fine control over film growth and microstructure.
- Deposition of thin selenium films onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Compositional analysis such as secondary ion mass spectrometry (SIMS), where sputtered atoms are identified to detect even very low impurity levels.
- Research and development work that can later be scaled to medium and large substrate production batches.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.999% |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01SE09
- Material: Selenium (Se)
- Type: Elastomer
- Size: 2''
- Thickness: 0.125''
—
—
