This silicon carbide (SiC) sputtering target is supplied indium-bonded, with a purity of 99.5%, a size of 2'' and a thickness of 0.125''. It serves as the source material for depositing SiC thin films by sputtering, where material is eroded from the target and deposited onto a substrate such as a silicon wafer.
Sputter deposition can coat substrates of many shapes and sizes and gives repeatable results. A process developed at small research and development scale can be scaled up to production batches covering medium to large substrate areas. Depending on the process parameters, chemical reactions may take place on the target surface, in flight or on the substrate. The number of adjustable parameters makes the process complex, but it gives experienced users close control over film growth and microstructure.
- Deposition of silicon carbide thin films onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Analytical work such as secondary ion mass spectrometry (SIMS), where the sample is sputtered at a constant rate to determine composition and detect trace impurities.
- Research related to space weathering, in which sputtering alters the physical and chemical properties of airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.5% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01SI61
- Material: Silicon Carbide (SiC)
- Bonding: Indium
- Size: 2''
- Thickness: 0.125''
—
—
