This silicon dioxide (SiO2) sputtering target is made of fused quartz with a purity of 99.995%. It measures 3'' in diameter and 0.125'' thick, is supplied with indium, and is sold as a single piece for sputter deposition systems.
Sputtering deposits thin films of many different materials onto substrates of varied shapes and sizes. The process is repeatable, so work that starts in small research and development projects can move on to production batches covering medium to large substrate areas.
Depending on the process parameters, chemical reactions may take place at the target surface, in flight or on the substrate. The number of adjustable parameters makes sputter deposition a complex technique, but it gives experienced users close control over film growth and microstructure.
- Thin film deposition, where material eroded from the target is deposited onto a substrate such as a silicon wafer.
- Sputter etching in cases that need highly anisotropic etching and where selectivity is not a concern.
- Material analysis such as secondary ion mass spectrometry (SIMS), where the sample is sputtered at a constant rate to identify its composition and trace impurities.
- Research into space weathering, the sputtering process that alters the surfaces of airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.995% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01SI79
- Material: Silicon Dioxide (SiO2), Fused Quartz
- Size: 3''
- Thickness: 0.125''
- Bonding: indium
- Product code: NG0ST01SI79
—
—
