This styrene-butadiene rubber (SBR) binder is a water-based polymer emulsion for lithium-ion battery electrodes. It serves as a primary binder in Li-ion anodes and suits all anode chemistries, and the same aqueous binder can also be used when preparing cathode slurries.
Supplied as a milky white liquid emulsion, the binder has a total solids content of 51.3 wt%, a pH of 6-7 and a Brookfield viscosity of 159 mPa.s. Its composition lists 24-26 wt% styrene, 71-73 wt% butadiene and 5 wt% carboxyl, with a vitrification temperature of -18°C.
In electrode formulations, SBR holds active material particles together and bonds them to the current collector while keeping the electrode flexible. It is often paired with carboxymethyl cellulose (CMC): SBR provides elasticity and adhesion, while CMC helps control slurry viscosity and particle dispersion. Because it is an emulsion, binder loading should be calculated from its solids content. Available in 500 ml and 1000 ml packs.
- Polymer binder in lithium-ion battery anodes to improve particle cohesion, electrode adhesion and mechanical integrity.
- Binding graphite particles and adhering them to copper current collectors during electrode fabrication.
- Flexible binder component in silicon-based anode research to help accommodate volume changes during cycling.
- Water-based anode slurry formulations for electrode coating and manufacturing.
- SBR/CMC binder systems combining binding, flexibility and rheological control in aqueous electrodes.
- Battery R&D on binder optimization, electrode durability and cycling performance.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | — |
| Category | — |
| Pack sizes | 500 ml, 1000 ml |
| Physical form | Milky white liquid emulsion |
| Storage | 0-38°C |
- Product code: NG08BE0308
- Total Solids (wt%): 51.3
- Styrene (wt%): 24-26
- Butadiene (wt%): 71-73
- Carboxyl (wt%): 5
- pH: 6-7
- Brookfield Viscosity (mPa.s): 159
- Solubility: Water-Soluble
- Relative Density (water=1): 1.52
- Relative Vapor Density (air=1): 1.23
- Vitrification Temperature: -18°C
Store at 0-38°C in tightly sealed, compatible containers, protected from contamination and freezing. Before use, check the emulsion for unexpected separation or coagulation, follow the product Safety Data Sheet (SDS), wear suitable protective equipment and take measures to prevent spills.
—
