This tin oxide (SnO2) sputtering target from Nanografi is a 99.99% purity source material measuring 1'' in size and 0.250'' in thickness. It is intended for sputter deposition, where material is eroded from the target and deposited as a thin film on a substrate such as a silicon wafer.
Sputtering is an established way to coat substrates of many shapes and sizes with thin films. The process is repeatable, works well for small research and development work, and can be scaled to production batches covering medium to large substrate areas.
Depending on the process parameters, chemical reactions may take place on the target surface, in flight, or on the substrate itself. Although the number of variables makes sputter deposition a complex technique, it gives experienced users considerable control over film growth and microstructure.
- Thin film deposition onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Material analysis by etching, as in secondary ion mass spectrometry (SIMS), to determine composition and detect very low impurity levels.
- Scaling deposition processes from research and development to medium and large production substrates.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.99% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01SN18
- Material: Tin Oxide (SnO2)
- Size: 1''
- Thickness: 0.250''
- Product code: NG0ST01SN18
—
—
