This tin oxide (SnO2) sputtering target from Nanografi is a source material for depositing thin films by sputtering. It has a purity of 99.99%, a size of 2'' and a thickness of 0.125'', and is supplied as a single piece.
In sputter deposition, material is eroded from the target and deposited onto a substrate such as a silicon wafer. The method works with substrates of many shapes and sizes, gives repeatable results, and can move from small research and development work to production batches covering medium to large substrate areas.
Depending on the process parameters, chemical reactions may take place at the target surface, in flight or on the substrate. The number of adjustable parameters makes sputtering a complex technique, but it also gives experienced users close control over film growth and microstructure.
- Deposition of tin oxide thin films onto substrates such as silicon wafers.
- Sputter etching where a high degree of etching anisotropy is required and selectivity is not a concern.
- Materials analysis techniques such as secondary ion mass spectrometry (SIMS), where sputtered atoms are identified and measured to determine composition and trace impurities.
- Scaling sputter processes from research and development to medium and large area production batches.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.99% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01SN19
- Material: Tin Oxide (SnO2)
- Size: 2''
- Thickness: 0.125''
- Product code: NG0ST01SN19
—
—
