This tin oxide (SnO2) sputtering target from Nanografi is a 99.99% purity source material for depositing thin films by sputtering. It measures 3'' in size with a thickness of 0.250'' and is supplied as a single piece.
In sputter deposition, material is eroded from the target and transferred onto a substrate such as a silicon wafer. The technique works on substrates of many shapes and sizes, gives repeatable results, and can move from small research and development work to production batches covering medium to large substrate areas.
Depending on the process parameters, chemical reactions may take place on the target surface, in flight or on the substrate. Although these many variables make sputtering a complex process, they give experienced users close control over film growth and microstructure.
- Deposition of tin oxide thin films onto substrates such as silicon wafers.
- Sputter etching where a high degree of etching anisotropy is required and selectivity is not a concern.
- Analytical work such as secondary ion mass spectrometry (SIMS), where material sputtered at a constant rate is identified by mass spectrometry to determine composition and detect very low impurity levels.
- Studies related to space weathering, in which sputtering alters the properties of airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.99% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01SN22
- Material: Tin Oxide (SnO2)
- Size: 3''
- Thickness: 0.250''
—
—
