This Nanografi tin (Sn) sputtering target is an elastomer-bonded target with 99.99% purity, sized at 1'' with a thickness of 0.125''. It serves as the source material for depositing thin tin films by sputtering, where material eroded from the target settles onto a substrate such as a silicon wafer.
Sputter deposition can coat substrates of many shapes and sizes, and the process is repeatable. It suits small research and development work and can be scaled to production batches covering medium to large substrate areas. Depending on process parameters, chemical reactions may take place at the target surface, in flight or on the substrate.
Because sputtering involves many adjustable parameters, it is a complex technique, but this gives experienced users close control over film growth and microstructure. Supplied as one piece.
- Thin film deposition of tin onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Material analysis by etching, as in secondary ion mass spectroscopy (SIMS), to determine composition and detect very low impurity levels.
- Research related to space weathering processes that alter airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.99% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01SN14
- Material: Tin (Sn)
- Size: 1''
- Thickness: 0.125''
- Bonding: Elastomer
- Product code: NG0ST01SN14
—
—
