This titanium dioxide (TiO2) sputtering target from Nanografi is a 99.99% purity source material for depositing thin films by sputtering. It measures 8'' in size with a thickness of 0.250'', and its colour ranges from beige to white.
In sputter deposition, material is eroded from the target and transferred onto a substrate such as a silicon wafer. The technique works on substrates of many shapes and sizes, gives repeatable results, and scales from small research and development work up to production batches covering medium to large substrate areas.
Depending on process parameters, chemical reactions may take place at the target surface, in flight, or on the substrate. The number of adjustable parameters makes sputtering a complex process, yet it gives experienced users considerable control over film growth and microstructure.
- Deposition of thin films onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Materials analysis by etching away target material, as in secondary ion mass spectroscopy (SIMS) for composition and trace impurity detection.
- Research related to space weathering, where sputtering alters the surfaces of airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.99% |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01TI70
- Material: Titanium Dioxide (TiO2)
- Size: 8''
- Thickness: 0.250''
- Colour: Beige to White
—
—
