This tungsten disulfide (WS2) micron powder from Nanografi has a nominal particle size of 1 µm and a stated purity of 99.9%, with an assay of ≥99.91 wt%. It is suited to work under high temperature and high pressure.
The powder tolerates temperatures from -270º C to 650º C in ordinary atmosphere and from -188º C to 1316º C under vacuum. When formulated into mixtures and applied as a coating on mating or moving parts, it lowers friction and improves lubricity and load bearing capacity over extended operating cycles.
Particle size analysis gives D10 of 0.78 µm, D50 of 1.23 µm and D90 of 1.45 µm. Impurity levels for carbon, SiO2, iron, phosphorus, sulfur, antimony and cadmium are listed in the specifications below.
- Friction-reducing coatings for automotive parts and racing car engines.
- Lubricating coatings for aerospace and marine components.
- Coatings for bearings, shafts, precision gears, chains and machinery components.
- Wear-reducing coatings for cutting tools, blades, slitters and knives.
- Coatings for valve components and pistons, and use in mold release.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | ≥99.91 wt% |
| Category | — |
| Pack sizes | — |
| Physical form | — |
| Storage | — |
- Product code: NG11EM01017
- C Content: 128 ppm
- SiO2 Content: 111 ppm
- Fe Content: 132 ppm
- P Content: 43 ppm
- S Content: 30 ppm
- Sb Content: 2 ppm
- Cd Content: <1 ppm
- D10: 0.78 µm
- D50: 1.23 µm
- D90: 1.45 µm
- Temperature resistance (atmosphere): -270º C to 650º C
- Temperature resistance (vacuum): -188º C to 1316º C
—
—
