This tungsten (W) sputtering target from Nanografi is an elastomer-bonded target with 99.95% purity, measuring 2'' in size and 0.125'' in thickness. It serves as the source material for depositing thin tungsten films by sputtering, where material is eroded from the target and deposited onto a substrate such as a silicon wafer.
Sputter deposition can coat many substrate shapes and sizes and gives repeatable results. A process developed in small research projects can be scaled up to production batches covering medium to large substrate areas. Depending on the process parameters, chemical reactions may take place at the target surface, in flight or on the substrate. The number of adjustable parameters makes the technique complex, but it gives experienced users close control over film growth and microstructure.
Beyond deposition, sputtering is also used for anisotropic etching and for surface analysis techniques such as secondary ion mass spectrometry (SIMS).
- Thin film deposition of tungsten onto substrates such as silicon wafers.
- Sputter etching where a high degree of etching anisotropy is required and selectivity is not a concern.
- Material analysis by sputtering, such as secondary ion mass spectrometry (SIMS), to determine composition and detect very low impurity levels.
- Research into space weathering processes that alter airless bodies such as asteroids and the Moon.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.95% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01TU12
- Material: Tungsten (W)
- Size: 2''
- Thickness: 0.125''
- Bonding: Elastomer
- Product code: NG0ST01TU12
—
—
