This vanadium oxide (V2O5) sputtering target from Nanografi is a 99.9% purity source material for depositing thin films by sputtering. It measures 8'' in size with a thickness of 0.250'' and is supplied as a single piece.
Sputtering builds thin films by eroding material from a target and carrying it onto a substrate such as a silicon wafer. The technique works with many substrate shapes and sizes, gives repeatable results, and scales from small research and development work up to production batches covering medium to large substrate areas.
Depending on process parameters, chemical reactions may take place at the target surface, in flight or on the substrate. The number of adjustable parameters makes sputter deposition complex, yet it gives experienced users fine control over film growth and microstructure.
- Thin film deposition of vanadium oxide onto substrates such as silicon wafers.
- Sputter etching where high etching anisotropy is required and selectivity is not a concern.
- Materials analysis by sputtering, as in secondary ion mass spectrometry (SIMS), to determine composition and detect very low impurity levels.
- Research and development projects that may later be scaled up to production batches.
| Brand | Nanografi |
|---|---|
| CAS number | — |
| Molecular formula | — |
| Purity | 99.9% |
| Category | — |
| Pack sizes | 1 piece |
| Physical form | — |
| Storage | — |
- Product code: NG0ST01VA29
- Material: Vanadium Oxide (V2O5)
- Size: 8''
- Thickness: 0.250''
- Product code: NG0ST01VA29
—
—
